Question 6 of 341

A technician is tasked with performing a room readiness assessment in preparation for an immersive video endpoint. What are three Cisco best practices regarding lighting recommendations for the room? (Choose three.)

Answer

Suggested Answer

The suggested answer is A, C, E.

Reference: http://www.cisco.com/en/US/solutions/collateral/ns669/c07-643449-00_tp_dg.pdf
In summary, Immersive Cisco TelePresence rooms should be designed with lighting that is:
Kelvin color temperature of 4000 or 4100K to match the built-in Cisco TelePresence endpoint lighting, and to reproduce colors accurately on screen.
CRI of 82 to 100.
Facial lighting from 200 to 400 lux, with these values measured with the Cisco TelePresence endpoint off.
Shoulder lighting not to exceed twice the values of the facial lighting, and also measured with the Cisco TelePresence endpoint off.
Light in all areas of the room within the camera field of view should not fluctuate more than 100 lux within the room. In other words, lighting is evenly dispersed throughout the room. This includes lighting at the room walls, which should be equal to or less than the facial lighting and should differ no more than 100 from rest of the room.
Implementation of a dimming lighting control system is highly recommended to adjust the intensity of light in the room without needing to precisely calculate the overall lighting levels in advance, and to ensure reproducible results with preset lighting scenes.
Regardless of fixture choices, indirect fluorescent lighting fixtures provide the best results for ambience and amount of dispersed lighting, and asymmetric fixtures provide the most efficient and predictable option within the range of indirect fixtures available
Question 7 of 341

Refer to the exhibit.

Exam 210-065: Question 7 - Image 1

A network engineer configures a Cisco Unified Communications Manager and VCS integration via a SIP trunk. Endpoint A is able to conduct video calls toEndpoint B. When Endpoint A attempts to share presentation content with Endpoint B, Endpoint B sees the presentation video on the main screen rather than on the presentation display. What is the cause?

Answer

Suggested Answer

The suggested answer is D.

Reference: http://www.cisco.com/c/dam/en/us/td/docs/telepresence/infrastructure/vcs/config_guide/
Cisco_VCS_Cisco_Unified_Communications_Manager_Deployment_Guide_CUCM_8_9_and_X7-2.pdf

Configuring the SIP Profile for phone devices This creates the SIP Profile that is to be applied to all phone devices.
1. On Unified CM, go to Device> Device Settings> SIP Profile.
2. Click Copy against the Standard SIP Profile.
3. Configure the following fields, leaving everything else a sits default value:
Exam 210-065: Question 7 - Image 2
4. Click Save D
Question 8 of 341

Which three features does Cisco VCS provide? (Choose three.)

Answer

Suggested Answer

The suggested answer is B, D, E.

Reference: http://www.cisco.com/c/en/us/products/collateral/unified-communications/telepresence-video-communication-server-vcs/data_sheet_c78-626491.html
Cisco VCS features:-
✑ SIP registrar and SIP proxy server
✑ H.323 gatekeeper interoperability and interworking between SIP and H.323 standards-compliant endpoints and support for communication with IBM Lotus
Same time and Microsoft Lync environments, including Microsoft Lync 2013 (H.264 SVC) clients
Question 9 of 341

A Unified Communications engineer wants to configure a Cisco TelePresence SX endpoint using static IP addressing to use a different TFTP server. Which path will allow the engineer to complete this configuration?

Answer

Suggested Answer

The suggested answer is D.

Reference: http://www.cisco.com/c/en/us/support/docs/conferencing/telepresence-management-suite-tms/200263-Configure-TMS-to-change-Provisioning-of.html
Using Web interface
1. Navigate to Configuration > System Configuration > Provisioning on the endpoint.
2. Navigate to ExternalManager section and enter the Address, which can be an IP address, DNS name or the path of the External Manager which is the CUCM cluster TFTP server address . Click Save.
3. Navigate to Mode and set the provisioning mode to CUCM. Click Save.
Question 10 of 341

Which two protocols can be used with the Cisco TelePresence Content Server to allow users to share content from their laptops? (Choose two.)

Answer

Suggested Answer

The suggested answer is A, B.

Reference: http://www.cisco.com/c/en/us/about/press/internet-protocol-journal/back-issues/table-contents-57/153-binary.html http://www.cisco.com/c/en/us/td/docs/telepresence/infrastructure/articles/cisco_telepresence_enable_dual_video_duo_people_content_h239_codian_kb_69.html


Protocol Details -
The basic concept of floor control is analogous to managing a live in-person presentation, where you want to control who is presenting, manage and transition your presenters, and maintain a feedback loop. Also important is the ability to allow a presenter to show slides and share with your audience a white board or transparency projector.
Dual video, Duo Video, People + Content and H.239 are all terms that describe support for a second live video channel in an H.323 call. Such a channel is most often used for the transmission of content, like the screen of a presenter's PC (so the term 'content channel' is also used). The terms all have slightly different meanings. Dual video is a generic term describing this capability. Duo Video and People + Content are proprietary implementations from Cisco TelePresence and
Polycom respectively.H.239 is the ITU standard for a second video channel; this is supported by all the major vendors, and is the only content channel standard supported by Cisco acquired Codian products or Cisco TelePresence Serial Gateway Series products on H.323 video calls.
